Huawei 150kW Commercial Solar Inverter

Huawei Large-scale commercial solar inverter

The Huawei SUN2000-150K-MG0 Solar Inverter is a high-capacity, three-phase, grid-tied inverter designed for large commercial and industrial solar power installations. With a rated AC output of 150kW, it is suitable for businesses, factories, warehouses and large facilities looking to convert solar energy into usable electricity efficiently.

Featuring advanced Huawei Smart PV technology and a maximum conversion efficiency of 98.8% at 480V, this inverter supports high-performance solar installations designed to reduce dependence on grid electricity and improve long-term energy management.

KSh 880,000.00
Pay on Mpesa Till No.: 8749690

Easy
payment

24 hours
delivery
Category:

The Huawei SUN2000-150K-MG0 features seven Maximum Power Point Tracking (MPPT) trackers, supporting flexible solar string configuration for large photovoltaic systems. Each MPPT can accommodate up to three inputs, allowing a maximum of 21 PV string inputs.

With a maximum DC input voltage of 1,100V and an MPPT operating voltage range of 200–1,000V, the inverter gives solar system designers flexibility when planning large rooftop or ground-mounted installations. Correct string configuration helps optimise solar generation while accounting for different array layouts and operating conditions.

Smart Monitoring and Advanced System Protection

The Huawei SUN2000-150K-MG0 combines intelligent monitoring with integrated electrical protection features to support reliable operation in demanding commercial solar environments.

Key features include arc fault protection, PV string fault monitoring, DC and AC Type II surge protection, anti-islanding protection and smart string-level disconnection. Compatible Huawei FusionSolar monitoring solutions help users and installers monitor solar production and identify system issues.

Its IP66-rated enclosure and smart air-cooling system make it suitable for appropriately designed outdoor installations, subject to the manufacturer’s installation requirements.

Key Technical Specifications

Feature Specification
Model SUN2000-150K-MG0
Rated AC output 150kW
Maximum active power 165kW
Maximum efficiency 98.6% at 400V; 98.8% at 480V
MPPT trackers 7
Maximum PV string inputs 21
Maximum DC input voltage 1,100V
MPPT voltage range 200–1,000V
AC output voltage 380V / 400V / 480V
Grid frequency 50Hz / 60Hz
Protection rating IP66
Cooling Smart air cooling
Monitoring Huawei FusionSolar-compatible solutions

Specifications are based on Huawei’s published documentation. Confirm the exact model variant, applicable grid requirements and regional datasheet before purchase.

Applications for Large Commercial and Industrial Solar Projects

The Huawei SUN2000-150K-MG0 is designed for large-scale solar PV systems serving:

  • Factories and manufacturing facilities

  • Large warehouses and distribution centres

  • Commercial buildings and office complexes

  • Hotels and large hospitality properties

  • Agricultural processing facilities

  • Industrial and ground-mounted solar installations

For facilities with substantial daytime electricity consumption, a properly designed solar PV system can help offset grid electricity use and improve energy cost management.

Important: This is a grid-tied solar inverter, not a standalone battery backup inverter. It should not be assumed to supply power during a grid outage. Any storage or backup requirements must be addressed through a compatible system design.
